MV3406 - Marine Boilers And Steam Engineeering Syllabus Regulation 2021 Anna University

Marine Boilers And Steam Engineeering is a dynamic subject that continuously shifts from one perspective to another. However, the technicality is the same even if the theories and perspectives vary. Hence to gain knowledge in this subject you must be equipped with more vicious on the syllabus.

In this article, we tried to provide the required syllabus of the MV3406 Marine Boilers And Steam Engineeering subject to gain command of the subject matter. By the end of the course, you will be trained and guided with useful knowledge regarding technical english, which plays a major role in understanding the core of this B.E Marine Engineering semester IV related to Affiliated institutions awarded by Anna University course. Hope this information is useful. Kindly share it with your friends. Comment below if you have queries regarding the syllabus.

If you want to know more about the syllabus of B.E. Marine Engineering connected to an affiliated institution’s four-year undergraduate degree program. We provide you with a detailed Year-wise, semester-wise, and Subject-wise syllabus in the following link B.E. Marine Engineering Syllabus Regulation 2021 Anna University.

Aim Of Concept:

To Impart the knowledge to the students on

  • Marine boilers and steam engines.
  • Operation & Maintenance of Boilers
  • The concept of marine steam plants operations
  • Lubrication for Steam Engines and Turbines
  • Operation and maintenance of turbines

MV3406 – Marine Boilers And Steam Engineeering Syllabus

Unit I: Marine Boilers & Boiler Mountings

Scotch Boiler, Cochran, Spanner, Clarkson thimble tube, Waste heat recovery calculation, Lamont exhaust gas boiler, Composite boilers, Water tube boilers – Babcock Wilcox, Foster Wheeler – Dtype, Double evaporation boilers. Safety Valves – Improved High Lift, Full lift and full Bore type: Gauge glass – Ordinary plate type and remote Indicator; Automatic feed regulator, three element High & Low water level alarms, Main Steam stop valve, Retractable type Soot blower etc.

Unit II: Operation & Maintenance Of Boilers

Pre-commissioning procedures, Hydraulic tests, steam raising and Operating procedures, Action in the event of shortage of water. Regular boiler water tests on board. Blowing down of boiler, Laying up a boiler; general maintenance, External and internal tube cleaning. Tube renewals, etc., maintenance, inspection and survey of boilers. Refractory: Purposes of refractory, types of refractory and reasons for failure. Oil burning: Procedure of Liquid fuel burning in open furnace, Various types of atomizer, Furnace arrangement for oil burning, Boiler Control System i.e. master control, fuel control, air control and viscosity control, Introduction to Automation.

Unit III: Marine Steam Plants

Steam engines – History of multiple expansion marine reciprocating engines &steam turbines. Description of different types of steam turbines. Layout of plant – General layout of plant & description of a modern geared steam turbine installation including auxiliaries in modern use, open and closed feed system.
Condensers – Types of condensers, constructional details, location & working principles, contraction and expansion allowances, leak test. Effect of change of temperature, circulating water quantity, change of main engine power, condenser surface.

Unit IV: Lubrication For Steam Engines And Turbines

Suitable oils and their properties, lubrication of main bearings, thrust bearings and gears. Gravity and pressure lubrication-oil system and emergency lubrication arrangement.

MV3406 - Marine Boilers And Steam Engineeering Syllabus Regulation 2021 Anna University

Unit V: Operation And Maintenance Of Turbines

Turbine drain system, turbine gland system, warming through a turbine plant, control of speed and power of propulsion, throttle valve control and nozzle control, emergency controls, emergency operation of turbines, vibration in marine steam turbine, steam turbine losses. Breakdown and faultfinding. Selection of materials: Materials used in various components like blades, rotors, casings, sealing glands, gears etc. & their justification.

Text Books:

  1. J.H. Milton & R.M. Leach, “Marine Steam Boilers”, 4th Edition, Butter worth, London, 1980
  2. C. McBirnie, “Marine Steam Engines and Turbines”, 4th Edition, Butter worth, London 1980.
  3. Thomas D. Morton, “Steam Engineering Knowledge for Marine Engineers”, 3rd Edition, Thomas Reed Publications, London 1979.

References:

  1. GTH. Flanagan, “Marine Boilers” 3rd Edition, Butter worth, London, 2001.
  2. K.M.B. Donald, “Marine Steam Turbines”, 1st Edition, Institute of Marine Engineers, London, 1977.
  3. Leslie Jackson and Thomas D. Morton, “General Engineering Knowledge for Marine Engineers, Reed’s Vol.8, Thomas Reeds Publication, United Kingdom, 2003
  4. Norros. A, “Operation of Machinery in Ships Steam Turbines, Boilers”, Marine Engineering Practice, Vol 2, Part 15, IMarEST, London, 2000
