Regulation 2021 Anna University Code – ME3592 deals with the semester – V Metrology and Measurements Syllabus of B.E Mechanical Engineering. Most of the semester syllabus tries to give both practical and theoretical knowledge to the students. To acquire the proper knowledge regarding the studies to prepare for the examination, need a detailed syllabus right?
This article will assist you in gaining most of the syllabus details. We tried our best to provide the required syllabus info. Chapter-wise syllabus along with reference books written by experts and textbooks added. Hence in this article ME3592 – Metrology and Measurements syllabus, we include all the details regarding the examination. Students can easily get all the data regarding the syllabus on one page. Hope you will understand the syllabus. And All the best for your exams. Don’t forget to share it with your friends.
If you want to know more about the syllabus of B.E Mechanical Engineering connected to an affiliated institution’s four-year undergraduate degree program. We provide you with a detailed Year-wise, semester-wise, and Subject-wise syllabus in the following link B.E Mechanical Engineering Syllabus Anna University Regulation 2021.
Aim Of Objectives:
- To learn basic concepts of the metrology and importance of measurements.
- To teach measurement of linear and angular dimensions assembly and transmission elements.
- To study the tolerance analysis in manufacturing.
- To develop the fundamentals of GD & T and surface metrology.
- To provide the knowledge of the advanced measurements for quality control in manufacturing industries.
ME3592 – Metrology and Measurements Syllabus
Unit – I: Basics Of Metrology
Measurement – Need, Process, Role in quality control; Factors affecting measurement – SWIPE; Errors in Measurements – Types – Control – Measurement uncertainty – Types, Estimation, Problems on Estimation of Uncertainty, Statistical analysis of measurement data, Measurement system analysis, Calibration of measuring instruments, Principle of air gauging- ISO standards.
Unit – II: Measurement Of Linear, Angular Dimensions, Assembly And Transmission Elements
Linear Measuring Instruments – Vernier caliper, Micrometer, Vernier height gauge, Depth Micrometer, Bore gauge, Telescoping gauge; Gauge blocks – Use and precautions, Comparators – Working and advantages; Opto-mechanical measurements using measuring microscope and Profile projector – Angular measuring instruments – Bevel protractor, Clinometer, Angle gauges, Precision level, Sine bar, Autocollimator, Angle dekkor, Alignment telescope. Measurement of Screw threads – Single element measurements – Pitch Diameter, Lead, Pitch. Measurement of Gears – purpose – Analytical measurement – Runout, Pitch variation, Tooth profile, Tooth thickness, Lead – Functional checking – Rolling gear test.
Unit – III: Tolerance Analysis
Tolerancing– Interchangeability, Selective assembly, Tolerance representation, Terminology, Limits and Fits, Problems (using tables IS919); Design of Limit gauges, Problems. Tolerance analysis in manufacturing, Process capability, tolerance stackup, and tolerance charting.
Unit – IV: Metrology Of Surfaces
Fundamentals of GD & T- Conventional vs Geometric tolerance, Datums, Inspection of geometric deviations like straightness, flatness, roundness deviations; Simple problems – Measurement of Surface finish – Functionality of surfaces, Parameters, Comparative, Stylus based and Optical Measurement techniques, Filters, Introduction to 3D surface metrology- Parameters.
Unit – V: Advances In Metrology
Lasers in metrology – Advantages of lasers – Laser scan micrometers; Laser interferometers – Applications – Straightness, Alignment; Ball bar tests, Computer Aided Metrology – Basic concept of CMM – Types of CMM – Constructional features – Probes – Accessories – Software – Applications – Multisensor CMMs. Machine Vision – Basic concepts of Machine Vision System – Elements – Applications – Online and inprocess monitoring in production – Computed tomography – White light Scanners.
Text Books:
- Dotson Connie, “Dimensional Metrology”, Cengage Learning, First edition, 2012.
- Mark Curtis, Francis T. Farago, “Handbook of Dimensional Measurement”, Industrial Press, Fifth edition, 2013.
References:
- AmmarGrous, J “Applied Metrology for Manufacturing Engineering”, Wiley-ISTE, 2011.
- Galyer, J.F.W. Charles Reginald Shotbolt, “Metrology for Engineers”, Cengage Learning EMEA; 5th revised edition, 1990.
- National Physical LaboratoryGuideNo. 40, No. 41, No. 42, No. 43, No. 80, No. 118, No. 130, No. 131. http://www.npl.co.uk.
- Raghavendra N.V. and Krishnamurthy. L., Engineering Metrology and Measurements, Oxford University Press, 2013.
- Venkateshan, S. P., “Mechanical Measurements”, Second edition, John Wiley &Sons, 2015.
